10. - Maintenance and storage
GMD16-GMD20
75
KN225BGB_A
Disc mower
10.3.3 Checking cutterbar oil level
- Regularly check the cutterbar oil level:
• Place cutter bar in vertical position.
• Remove filler plug (1) and its washer.
• Check the oil level.
• The oil must reach the lower edge of the filling
hole.
• Top up if necessary.
• Clean and reinstall filler plug (1) and its
washer. Replace if necessary.
Before checking that the discs rotate freely by hand:
If it is found that the transmission case is very hot
to touch by hand, there is no cause of alarm
provided:
• Lubrication recommendations have
been respected.
• Discs can be rotated freely by hand
when the machine is hot.
Before carrying out any maintenance or
repairs on the machine, switch off the tractor
engine, remove ignition key, wait until all
moving parts have come to a standstill and
apply park brake.
1
