9.9.3 Putting the machine into work position
- Position lever (1) in position (a).
- Operate hydraulic pump control lever to release
transport lock.
- Pull the release cord until transport lock is released
(2).
- Fully rotate knob (3) counterclockwise.
9.10 Device for mowing at an angle of -
40°
GMD16 - GMD20
This equipment enables obtaining a maximum
cutter bar angle of -40°.
9.11 Wear plate
GMD16 - GMD20
Wear plates can be welded underneath the disc
guard to improve its resistance to wear in difficult
working conditions.
