KUHN GMD16 - 6.2.9 Adjusting the machine

GMD16-GMD20
48
6. - Putting into service
KN225BGB_A
Disc mower
- On machine side, attach guard chain to the main
frame (1).
6.2.9 Adjusting the machine
 Frame height and check chains.
Tractor fitted with a hydraulic position control
function:
- Lower tractor lift linkage to obtain a distance (H)
slightly exceeding 400 mm (1’4’’) between the
hitch pins and the ground.
- Note the corresponding lever position in the tractor
cab.
Immediately replace any worn or damaged
guard.
1
The distance between the Hitch pins and the
ground must be of 400 mm (1’4’’).
It is not necessary to use the check chain
supplied with the machine.
