6. - Putting into service
GMD16-GMD20
49
KN225BGB_A
Disc mower
Tractor not fitted with a hydraulic position
control function:
- Attach hook of check chain supplied with the
machine in one of the upper holes of the tractor top
link yoke.
- Lower the machine until the check chain is under
tension.
The tractor lift linkage is in working position.
The frame height is correct when:
• The cutterbar is resting on the ground.
• The check chain is under tension.
- Close hook eyelet with roll pin when properly
adjusted.
The distance between the Hitch pins and the
ground must be of 400 mm (1’4’’).
