8. - Instructions for work
GMD16-GMD20
59
KN225BGB_A
Disc mower
If the break-away latch releases too easily after
reset, tighten nut (1) to increase spring washer
compression slightly.
Basic adjustment:
L= 96 mm (3.8’’)
In case of clogging:
- Lift and lock front guard.
- Remove foreign body.
- Check that the mowing unit has not been
damaged.
- Check rotating components for damage.
- Lower and lock front guard.
Respect spring washer layout.
For proper functioning of the safety, measure L
must not be below 91 mm (3.60’’).
Before carrying out any maintenance or
repairs on the machine, switch off the tractor
engine, remove ignition key, wait until all
moving parts have come to a standstill and
apply park brake.
