9 Messages
%1 File %2 cannot be
read (formatting
error).
The format of the file
is incorrect, resulting
in the parsing of the
file being canceled.
The data from the file
cannot be used. The
default values are
used.
Check the format of
the file. See also the
corresponding XSD
file.
%1 no master or
slave circuit activated.
Neither the master
nor the slave ring of
the Interbus card has
been activated in the
IBSPCI.XML file.
No connection is
established to the
Interbus card. Com-
munication with the
Interbus card is not
possible.
Activate either the
master or the slave or
both.
%1 Loading of SVC
file aborted due to a
formatting error.
The format of the
command in the SVC
file is incorrect in at
least one line.
The loading of the
command from the
SVC file is aborted.
Depending on where
this cancellation
occurs, the Interbus
remains in the corre-
sponding state. The
driver continues to
boot, but without I/O
data traffic.
Correct or re-gener-
ate the SVC file.
%1 Loading of SVC
file aborted due to an
error in a firmware
service
An error occurred dur-
ing transmission of a
firmware service from
the SVC file. Either
the firmware service
is not correctly speci-
fied, or it could not be
executed, or it gener-
ates an error.
The loading of the
command from the
SVC file is aborted.
Depending on where
this cancellation
occurs, the Interbus
remains in the corre-
sponding state. The
driver continues to
boot, but without I/O
data traffic.
Check whether the
firmware service is
correctly specified.
The bus configura-
tion does not match
the configuration that
is to be loaded with
the SVC file.
%1 Error in connec-
tion to firmware.
No connection can be
established to the
message interface of
the firmware. The
maximum number of
connections has been
reached or the firm-
ware is in an error
state and can no lon-
ger be addressed.
No message commu-
nication with the firm-
ware.
Perform I/O reconfig-
uration. Activate reset
flag in IBSPCI.XML
file if required.
Unable to project %1
diagnostic registers
into I/O map.
A firmware service for
configuring the diag-
nostic registers into
the I/O map has
failed.
The diagnostic regis-
ters cannot be dis-
played in the I/O map.
Evaluate return val-
ues of the firmware
services. The I/O
addresses are incor-
rect.
%1 Unable to gener-
ate and start configu-
ration frame.
An error occurred on
loading the current
configuration and
starting the gener-
ated configuration
frame. To locate the
precise cause, the
error codes of the
firmware services
must be evaluated.
The Interbus is not
started and no I/O
data are exchanged.
Depends on the error
code of the firmware
services.
Message Reason Effect Remedy
