11-4
Appendix > Optional Equipment
4 With the memory connection terminal pointing toward the socket, align the cut-out part with the socket
terminal and insert directly in at an angle.
5 Carefully press the inserted memory down and into the machine.
6 Reinstall the covers.
Removing the Memory Module
To remove a memory module, remove the right cover and the memory slot cover from the machine. Then,
carefully push out the two socket clamps. Ease the memory module out of the socket to remove.
Verifying the Expanded Memory
To verify that the memory module is working properly, test it by printing a status page.
Notification/Report (page 8-21)
(5) "SD/SDHC Memory Card"
An SD/SDHC memory card is useful for storing fonts, macros, and overlays. The machine is equipped with a slot
for an SDHC memory card with a maximum size of 32 GB, and an SD memory card with a maximum size of 2 GB.
Reading the SD/SDHC Memory Card
Once inserted in the machine's slot, the contents of the SD/SDHC memory card can be read from the operation
panel or automatically when you power on or reset the machine.
Installing and Formatting the SD/SDHC Memory Card
To use an unused SD/SDHC memory card, you must first use the machine to format the SD/SDHC memory card.
For information on formatting an SD/SDHC memory card, consult your Service Representative.
1 Power off the machine and unplug the power cord.
To Next Page
