Kyocera FS-6030MFP - Detaching and Refitting the DP Paper Feed Roller and DP Separation Pulley

2K3/2L3
1-5-29
(2) Detaching and refitting the DP paper feed roller and DP separation pulley
Procedure
1. Open the DP top cover.
Figure 1-5-49
2. Pull the DP paper feed lever (yellow)
down and then open it.
3. Knock the DP paper feed roller down
forward.
Figure 1-5-50
DP top cover
DP paper feed roller
DP paper feed lever
(yellow)
