2K3/2L3
1-1-6
Figure 1-1-2
24
18
16
19
21
22
23
20
25
26
17
27
28
16. Front cover
17. Toner container
18. Waste toner box
19. Right cover 1
20. MP paper feed roller
21. Registration roller
22. Transfer roller
23. Feed shift guide
24. Original cover *
2
25. Drum unit
26. Developing unit
27. Toner container lever
28. Fuser unit
*2
: Only Model with original cover as standard
