Kyocera FS-9530DN - Fusing Is Poor; Image Is out of Focus; Image Is Not Square

2GZ/2G1-2
1-4-37
(15) Fusing is poor.
(16) Image is out of focus.
(17) Image is not square.
Print example Causes Check procedures/corrective measures
Wrong types of paper. Check if the paper meets specifications. Replace paper.
Defective pressure springs. Replace the pressure springs.
Flawed press roller. Replace the press roller (see page 1-5-21).
Flawed fuser heater. Replace the fuser heater (see page 1-5-22).
Print example Causes Check procedures/corrective measures
Drum condensation. Perform the drum refresh operation.
Print example Causes Check procedures/corrective measures
Laser scanner unit positioned incor-
rectly.
Adjust the installation position of the laser scanner unit (see
page 1-5-13).
