2GZ/2G1-2
1-3-1
1-3 Maintenance Mode
1-3-1 Maintenance mode
(1) Maintenance mode
The printer is equipped with a maintenance function which can be used to maintain and service the machine.
To run the maintenance mode, Insert a compact flash card to which the maintenance program has been written into the
printer and load the maintenance mode program to the printer using either method.
* Turn off and on the printer. The maintenance program will be automatically loaded into the printer.
* Load the maintenance mode program with read program.
* Enter the MENU mode and display [>>Maintenance] in the [Memory Card>], then press the OK key.
The maintenance mode can be executed from the MENU mode.
If the compact flash card is removed from the printer and then the printer is turned off and on, the maintenance mode pro-
gram will be deleted from the printer and the maintenance mode will be deleted from the MENU mode.
(2) Executing a maintenance item
Ready
--- A4 PLAIN
Print
Menu Map
Maintenance >
Mode H3SXX
Maintenance >
Mode H3SXX?
>Default Setting
[U002] XX
>Print Without
[U005] Paper XXX
>Drive Motors >
[U030]
>Check Switches>
[U031]
>Check Clutches>
[U032]
1. Press the MENU key.
2. Press the cursor up/down keys several times until [Maintenance >] is displayed.
3. Press the OK key.
3. Press the cursor right key.
Setting the factory default
data
See page 1-3-3.
Printing without paper
See page 1-3-3.
Checking motor operation
See page 1-3-4.
Checking switches for
paper conveying.
See page 1-3-4.
Checking clutch operation
See page 1-3-5.
Continue to the next page
The test page is
printed.
Maintenance >
Mode H3
S XX
Machine
code
Use
S: Service
Version
To Next Page
