2GZ/2G1
1-4-1
1-4 Troubleshoo ting
1-4-1 Paper misfeed detection
(1) Paper misfeed indication
When a paper misfeed occurs, the machine immediately stops printing and displays the jam location on the operation
panel.
To remove paper jammed in the machine, open the front cover, left cover or pull the cassette out.
To remove the jammed paper in optional document finisher, detach the finisher from the machine.
Paper misfeed detection can be reset by opening and closing the respective covers to turn safety switch off and on.
(2) Paper misfeed detection conditions
Figure 1-4-1
