Kyocera FS-9530DN Service Manual

2GZ/2G1-2
2-4-1
2-4 Appendixes
Maintenance parts list
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Upper/lower paper feed pulley PULLEY,PAPER FEED 2AR07220 - 4 1
Upper/lower separation pulley PULLEY,SEPARATION 2AR07230 - 4 2
Upper/lower forwarding pulley PULLEY FEED A 2BJ06010 - 4 5
MP paper feed pulley UPPER PULLEY,BYPASS 61706770 - 9 55
MP separation pulley PULLEY,SEPARATION 2AR07230 - 9 2
MP forwarding pulley PULLEY FEED A 2BJ06010 - 9 7
MP feed roller 1 ROLLER2 BYPASSFEED 302BL06541 2BL06541 10 14
MP feed roller 2 ROLLER4 BYPASSFEED 302BL06561 2BL06561 10 15
Left registration roller ROLLER REGIST 2FG16021 - 7 72
Right registration roller RIGHT ROLLER REGIST 302FG06211 2FG06211 5 51
Feed pulley PULLEY FEED 2BL16080 - 6,7 49,17
Feed roller 1 PULLEY MIDDLE FEED A 302GR06010 2GR06010 5 73
Feed roller 1 PULLEY MIDDLE FEED B 302GR06020 2GR06020 5 74
Feed roller 2 ROLLER B FEED 302BL06081 2BL06081 5 22
Feed roller 3 ROLLER C FEED 302BL06091 2BL06091 5 23
Registration switch SWITCH REGISTRATION 2FG27110 - 5 46
Left registration cleaner UNDER CLEANER REGIST 2BL07950 - 7 16
Registration guide GUIDE REGIST F 2BL16130 - 7 20
Right registration cleaner PARTS,REGISTRATION CLEAN 2BL93450 - 5 44
Transfer roller unit TR-710 302GR93281 2GR93281 7 A02
Developing unit DV-710 302G193041 2G193041 12 1
Drum unit DK-710 302G193031 2G193031 14 A01
Main charger unit MC-710 302GR93071 2GR93071 14 13
Fuser unit FK-710 U 302G193011 2G193011 13 A01
Fuser unit FK-710 E 302G193021 2G193021 13 A01
Eject roller ROLLER EXIT 302BL21021 2BL21021 8 27
Switchback roller ROLLER FEED SHIFT 302BL21031 2BL21031 8 28
Eject pulley PULLEY EXIT C 2BL21520 - 8 25
Eject pulley PULLEY EXIT 302GR28060 2GR28060 8 39
Switchback pulley PULLEY FEED SHIFT 2BL21330 - 6 29

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
