Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-4-9
(3) Paper misfeeds
Problem
Causes/check procedures Corrective measures
(1)
A paper jam in the
paper feed, convey-
ing or eject section is
indicated as soon as
the main power
switch is turned on.
A piece of paper torn from
print paper is caught around
feed switch 1/2/3, registra-
tion switch, eject switch or
feedshift switch.
Check visually and remove it, if any.
Defective switch. Run maintenance item U031 and turn switch on and off manually.
Replace the switch if indication of the corresponding switch on the
touch panel is not displayed in reverse.
Feed switch 1/2/3, registration switch, eject switch, feedshift
switch
(2)
A paper jam in the
paper feed section is
indicated during
printing (no paper
feed from cassette
1).
Jam code 10
Paper is extremely curled. Change the paper.
Check if the upper paper
feed pulley, separation pul-
ley or forwarding pulley of
the cassette 1 are
deformed.
Check visually and replace any deformed pulleys.
Broken feed switch 1 actua-
tor.
Check visually and replace switch.
Defective feed switch 1. Run maintenance item U031 and turn feed switch 1 on and off
manually. Replace the switch if indication of the corresponding
switch on the touch panel is not displayed in reverse.
Check if the upper paper
feed clutch malfunctions.
Run maintenance item U032 and select the upper paper feed
clutch on the touch panel to be turned on and off. Check the status
and remedy if necessary.
Electrical problem with the
upper paper feed clutch.
Check (see page 1-4-38).
(3)
A paper jam in the
paper feed section is
indicated during
printing (no paper
feed from cassette
2).
Jam code 11
Paper is extremely curled. Change the paper.
Check if the lower paper
feed pulley, separation pul-
ley or forwarding pulley of
the cassette 2 are
deformed.
Check visually and replace any deformed pulleys.
Broken feed switch 2 actua-
tor.
Check visually and replace switch.
Defective feed switch 2. Run maintenance item U031 and turn feed switch 2 on and off
manually. Replace feed switch 2 if indication of the corresponding
switch on the touch panel is not displayed in reverse.
Check if the lower paper
feed clutch malfunctions.
Run maintenance item U032 and select the lower paper feed
clutch on the touch panel to be turned on and off. Check the status
and remedy if necessary.
Electrical problem with the
lower paper feed clutch.
Check (see page 1-4-38).

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
