Kyocera FS-9530DN - Page 176

2GZ/2G1-1
2-3-12
YC23 1 SIOUT O 0/5 V DC SIOUT signal
Connected
to the main
PWB
2 SCLKIN I 0/5 V DC (pulse) CLOCK signal
3 SDIR O 0/5 V DC SDIR signal
4 SBSY O 0/5 V DC SBSY signal
5 EGIR O 0/5 V DC EGIR signal
6 SOIN O 0/5 V DC SOIN signal
7 SGND - - Ground
8 SYSRES O 0/5 V DC SYSRES signal
9 OUTPEN O 0/5 V DC OUTPEN signal
10 PVSYNC O 0/5 V DC (pulse) PVSYNC signal
11 5VSAFE O 5 V DC 5 V DC power output
12 SGND - - Ground
13 SGND - - Ground
14 PRST I 0/5 V DC PRST signal
Connector Pin No. Signal I/O Voltage Description
