Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-4-2
Section Description Conditions Specified time
System 04
Cover open
Cover is open during printing. -
05
Secondary paper feed
does not start
Secondary paper feed does not start within specified time
of arrival of paper at the registration section.
30 s
09
3000-sheet paper
feeder sequence error
jam
A communication sequence error occurs between the
machine and the 3000-sheet paper feeder.
-
Paper
feed
section
10
No paper feed from
cassette 1
Feed switch 1 (FSW1) does not turn on within the speci-
fied time of upper paper feed clutch (PFCL-U) turning on;
the clutch is then successively turned off for 1 s and
turned back on, but the switch again fails to turn on within
the specified time.
1152 ms
11
No paper feed from
cassette 2
Feed switch 2 (FSW2) does not turn on within the speci-
fied time of lower paper feed clutch (PFCL-L) turning on;
the clutch is then successively turned off for 1 s and
turned back on, but the switch again fails to turn on within
the specified time.
1209 ms
12
No paper feed from
optional cassette 3
Feed switch 3 (FSW3) does not turn on within the speci-
fied time of paper feeder paper feed clutch 1 (PFPFCL1)
turning on; the clutch is then successively turned off for 1
s and turned back on, but the switch again fails to turn on
within the specified time (paper feed from optional paper
feeder).
1209 ms
Feed switch 3 (FSW3) does not turn on within the speci-
fied time of paper feeder paper feed clutch 1 (PFPFCL1)
turning on; the clutch is then successively turned off for 1
s and turned back on, but the switch again fails to turn on
within the specified time (paper feed from optional 3000-
sheet paper feeder).
1582 ms
13
No paper feed from
optional cassette 4
The paper feeder feed switch (PFFSW) does not turn on
within the specified time of paper feeder paper feed
clutch 2 (PFPFCL2) turning on; the clutch is then succes-
sively turned off for 1 s and turned back on, but the switch
again fails to turn on within the specified time (paper feed
from optional paper feeder).
1209 ms
14
No paper feed from MP
tray
The MP feed switch (MPPFSW) does not turn on within
the specified time of the MP paper feed clutch (MPPFCL)
turning on; the clutch is then successively turned off for 1
s and turned back on, but the switch again fails to turn on
within the specified time.
3913 ms
15
Jam in paper feeder
horizontal paper con-
veying section 1
Paper path sensor 3 (PPSENS3) does not turn on within
specified time of paper feeder paper feed clutch 2
(PFPFCL2) turning on (paper feed from optional 3000-
sheet paper feeder).
637 ms
16
Jam in paper feeder
horizontal paper con-
veying section 2
Paper path sensor 2 (PPSENS2) does not turn on within
specified time of the paper path sensor 3 (PPSENS3)
turning on (paper feed from optional 3000-sheet paper
feeder).
681 ms
17
Jam in paper feeder
horizontal paper con-
veying section 3
Paper path sensor 1 (PPSENS1) does not turn on within
specified time of the paper path sensor 2 (PPSENS2)
turning on (paper feed from optional 3000-sheet paper
feeder).
417 ms

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
