Kyocera FS-9530DN Service Manual

2GZ/2G1
1-4-3
Paper
feed
section
18
Misfeed in vertical
paper conveying sec-
tion
The registration switch (RSW) does not turn on within
specified time of feed switch 1 (FSW1) turning on.
1283 ms
Feed switch 1 (FSW1) does not turn on within specified
time of feed switch 2 (FSW2) turning on.
1478 ms
Feed switch 2 (FSW2) does not turn on within specified
time of feed switch 3 (FSW3) turning on.
1474 ms
19
Misfeed in paper feeder
vertical paper convey-
ing section
Feed switch 3 (FSW3) does not turn on within specified
time of the paper feeder feed switch (PFFSW) turning on.
1217 ms
20
Misfeed in MP tray ver-
tical paper conveying
section
The registration switch (RSW) does not turn on within
specified time of the MP feed switch (MPFSW) turning
on.
3043 ms
21
Multiple sheets in paper
feed section
The feed switch 1 (FSW1) does not turn off within speci-
fied time of its turning on.
3357 ms - paper
length
The feed switch 2 (FSW2) does not turn off within speci-
fied time of its turning on.
3357 ms - paper
length
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional paper
feeder).
2617 ms
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional 3000-
sheet paper feeder).
1234ms
The paper feeder feed switch (PFFSW) does not turn off
within specified time of its turning on.
2617 ms
The MP feed switch (MPFSW) does not turn off within
specified time of its turning on.
3357 ms - paper
length
The feed switch 1 (FSW1) does not turn off within speci-
fied time of the upper paper feed clutch (PFCL-U) turning
on.
1152 ms
The feed switch 2 (FSW2) does not turn off within speci-
fied time of the lower paper feed clutch (PFCL-L) turning
on.
1209 ms
The feed switch 3 (FSW3) does not turn off within speci-
fied time of the paper feeder paper feed clutch 1
(PFPFCL1) turning on.
2643 ms
The paper feeder feed switch (PFFSW) does not turn off
within specified time of the paper feeder paper feed
clutch 2 (PFPFCL2) turning on.
3913 ms
The MP feed switch (MPFSW) does not turn off within
specified time of the MP paper feed clutch (MPPFCL)
turning on.
3913 ms
Section Description Conditions Specified time

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
