Kyocera FS-9530DN Service Manual

2GZ/2G1-2
2-3-8
YC9 A1 GND - - Ground
Connected
to the MP
feed switch,
toner con-
tainer sen-
sor,
developing
unit, toner
feed sole-
noid, toner
container
detection
switch and
drum unit
A2 MPFSW I 0/5 V DC MPFSW: On/Off
A3 +5VD O 5 V DC 5 V DC power output
A4 +5VD O 5 V DC 5 V DC power output
A5 TCS I 0/5 V DC TCS: On/Off
A6 GND - - Ground
A7 DEVP0 I 0/5 V DC Developing unit distinction signal
A8 +5VD O 5 V DC 5 V DC power output
A9 TNS I 0/5 V DC TNS: On/Off
A10 GND - - Ground
A11 DVUNITN I 0/5 V DC Developing unit detection signal
A12 FUSE_CUT O 0/5 V DC Developing unit FUSE CUT signal
A13 EEDATA I/O 0/5 V DC (pulse) Developing unit EEPROM DATA signal
A14 EESCLK O 0/5 V DC (pulse) Developing unit EEPROM CLOCK signal
B1 +24VDR O 24 V DC 24 V DC power output
B2 TNFSOL O 0/24 V DC TNFSOL: On/Off
B3 TCDSW I 0/5 V DC TCDSW: On/Off
B4 GND - - Ground
B5 DRUMP0 I 0/5 V DC Drum unit distinction signal
B6 GND - - Ground
B7 CL O 0/5 V DC CL: On/Off
B8 EEDATA I/O 0/5 V DC (pulse) Drum unit EEPROM DATA signal
B9 EESCLK O 0/5 V DC (pulse) Drum unit EEPROM CLOCK signal
B10 GND - - Ground
B11 DRUNITN I 0/5 V DC Drum unit detection signal
B12 +5VD O 5 V DC 5 V DC power output
B13 MCCM_FWD O 0/24 V DC MCCM: On/Off
B14 MCCM_REV O 0/24 V DC MCCM: On/Off
YC10 A1 GND - - Ground
Connected
to the regis-
tration
switch, fuser
unit, duplex
feed clutch,
duplex
paper con-
veying
switch and
cooling fan
motor 5 to
10
A2 RSW O 0/5 V DC RSW: On/Off
A3 +5VD O 5 V DC 5 V DC power output
A4 FUSER P0 I 0/5 V DC Fuser unit distinction signal
A5 3VD O 3.3 V DC 3.3 V DC power output
A6 FTH1 I Analog FTH1 detection voltage signal
A7 FUSE CUT O 0/5 V DC FTH1 FUSE CUT signal
A8 GND - - Ground
A9 GND - - Ground
A10 FTH2 STD I Analog FTH2 detection voltage signal
A11 FTH2 I Analog FTH2 detection voltage signal
B1 +24VDR O 24 V DC 24 V DC power output
B2 DUPFCL O 0/24 V DC DUPFCL: On/Off
B3 GND - - Ground
B4 DUPPCSW I 0/5 V DC DUPPCSW: On/Off
B5 +5VD O 5 V DC 5 V DC power output
B6 GND - - Ground
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
