Kyocera FS-9530DN Service Manual

2GZ/2G1
2-3-10
YC13 A1 GND - - Ground
Connected
to the feed
switch 2/3,
feed clutch
2/3, left
cover 2
switch,
upper/lower
lift motors,
lower lift
motor,
upper/lower
paper size
length
switches,
upper/lower
lift limit
switches
and upper/
lower paper
switches
A2 FSW3 I 0/5 V DC FSW3: On/Off
A3 +5VD O 5 V DC 5 V DC power output
A4 R24VDR O 24 V DC 24 V DC power output
A5 FCL3 O 0/24 V DC FCL3: On/Off
A6 GND - - Ground
A7 FSW2 I 0/5 V DC FSW2: On/Off
A8 +5VD O 5 V DC 5 V DC power output
A9 GND - - Ground
A10 LC2SW I 0/5 V DC LC2SW: On/Off
A11 +24VDR O 24 V DC 24 V DC power output
A12 FCL2 O 0/24 V DC FCL2: On/Off
A13 LM-U SW2 I 0/5 V DC LM-U SW2: On/Off
A14 GND - - Ground
A15 LM-U SW1 I 0/5 V DC LM-U SW1: On/Off
A16 GND - - Ground
A17 LM-U REM O 0/24 V DC LM-U: On/Off
A18 GND - - Ground
A19 PLSW-L I 0/5 V DC PLSW-L: On/Off
B1 GND - - Ground
B2 PLSW-U I 0/5 V DC PLSW-U: On/Off
B3 LM-L SW2 I 0/5 V DC LM-L SW2: On/Off
B4 GND - - Ground
B5 LM-L SW1 I 0/5 V DC LM-L SW1: On/Off
B6 GND - - Ground
B7 LM-L REM O 0/24 V DC LM-L: On/Off
B8 GND - - Ground
B9 LICSW-U I 0/5 V DC LICSW-U: On/Off
B10 +5VD O 5 V DC 5 V DC power output
B11 GND - - Ground
B12 PSW-U I 0/5 V DC PSW-U: On/Off
B13 +5VD O 5 V DC 5 V DC power output
B14 GND - - Ground
B15 LICSW-L I 0/5 V DC LICSW-L: On/Off
B16 +5VD O 5 V DC 5 V DC power output
B17 GND - - Ground
B18 PSW-L I 0/5 V DC PSW-L: On/Off
B19 +5VD O 5 V DC 5 V DC power output
Connector Pin No. Signal I/O Voltage Description

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
