2GZ/2G1
1-2-4
1. Remove three tapes.
Figure 1-2-3
1. Install the optional paper feeder as necessary.
1. Pull cassette 1 and 2 out.
Remove the lift plate stopper from each cas-
sette and attach it to the storage location.
When moving the machine, attach the lift
plate in original position.
Figure 1-2-4
Remove the tapes.
Tapes
Tape
Install the optional paper feeder.
Release of cassette lift plate.
Lift plate stopper
To Next Page
