2GZ/2G1-2
1-3-34
Service items Description
No. Items Description
(11) Service Call (Self diag-
nostic error) Log
# Count. Self diagnostic error
code
Remembers 1 to 8 of
occurrence of self diag-
nostics error. If the occur-
rence of the previous
diagnostics error is less
than 8, all of the diagnos-
tics errors are logged.
The total page count at
the time of the self diag-
nostics error.
Indicates the self
diagnostic errors and
codes.
(See page 1-4-18)
Example:
01.6000
01: Self diagnostic
error
6000: Self diagnostic
error code number
(12) Maintenance Log # Count. Item
Remembers 1 to 8 of
occurrence of replace-
ment. If the occurrence of
the previous replacement
of toner container is less
than 8, all of the occur-
rences of replacement are
logged.
The total page count at
the time of the replace-
ment of the toner con-
tainer.
This is virtually logged
as the occurrence of the
Toner Empty condition
since the replacement of
the toner container is not
precisely detectable.
Code of mainte-
nance replacing item
(1 byte, 2 categories)
First byte (Replac-
ing item)
01: Toner container
02: Maintenance kit
Second byte (Type
of replacing item)
00: (fixed)
(13) Counter Log
Comprised of three log
counters including paper
jams, self diagnostics
errors, and replacement of
the toner container.
(g) Jam (h) Self diagnostic error (i) Maintenance item
replacing
Indicates the log counter
of paper jams depending
on location.
Refer to Paper Jam Log.
All instances including
those are not occurred
are displayed.
Indicates the log counter
of self diagnostics errors
depending on cause.
(See page 1-4-18)
Example:
C6000: 4
Self diagnostics error
6000 has happened four
times.
Indicates the log
counter depending
on the maintenance
item for mainte-
nance.
T: Toner container
00: Black
M: Maintenance kit
00: (fixed)
Example:
T00: 1
The (black) toner
container has been
replaced once.
To Next Page
