Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-4-23
4200 BD steady-state problem
ASIC detects a BD error A for 2 s after
the polygon motor rotation has been sta-
bilized.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC8 on
the engine PWB and laser scanner unit, and
the continuity across the connector termi-
nals. Repair or replace if necessary.
Defective laser
scanner unit.
Replace the laser scanner unit.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
5300 Broken cleaning lamp wire
While the cleaning lamp is on, the bro-
ken cleaning lamp wire detection signal
is detected for 2 s continuously.
Defective cleaning
lamp.
Replace the cleaning lamp.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
6000 Fuser heater break
Fuser unit thermistor 1 is detected 40°C/
104°F below with 10 s continuously dur-
ing warm-up and ready in.
Defective fuser
heater M or S.
Replace the fuser heater M or S.
Installation defec-
tiveness on fuser
unit thermistor 1.
Check the mounting state of the fuser unit
thermistor 1. If any problem is found, repair
it.
Defective fuser unit
thermostat.
Replace the fuser unit thermostat.
Defective PWB. Replace the power source PWB or engine
PWB and check for correct operation.
6020 Abnormally high fuser unit thermistor
temperature
Fuser unit thermistor 1 or 2 is detected
230°C/446°F or more for 40 ms.
Installation defec-
tiveness on fuser
unit thermistor 1 or
2.
Check the mounting state of the fuser unit
thermistor 1 or 2. If any problem is found,
repair it.
Defective fuser unit
thermistor 1 or 2.
Replace the fuser unit thermistor 1 or 2.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
6030 Fuser unit thermistor break error
The thermistor break signal is detected
continuously for 500 ms.
Installation defec-
tiveness on fuser
unit thermistor 1 or
2.
Check the mounting state of the fuser unit
thermistor 1 or 2. If any problem is found,
repair it.
Defective fuser unit
thermistor 1 or 2.
Replace the fuser unit thermistor 1 or 2.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
6050 Abnormally low fuser unit thermistor
3 temperature
Fuser unit thermistor 1 is detected
100°C/212°F less than 1 s continuously
during printing.
Defective fuser
heater M or S.
Replace the fuser heater M or S.
Installation defec-
tiveness on fuser
unit thermistor 1.
Check the mounting state of the fuser unit
thermistor 1. If any problem is found, repair
it.
Defective PWB. Replace the power source PWB or engine
PWB and check for correct operation.
6400 Zero-cross signal error
While fuser heater ON/OFF control is
performed, the zero-cross signal is not
input within 3 s.
Defective PWB. Replace the engine PWB or power source
PWB and check for correct operation.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
