Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-4-31
8900 Backup memory data problem
(optional 3000-sheet document fin-
isher)
Read and write data does not match.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
finisher main PWB and the connector on the
engine PWB, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective finisher
main PWB.
Replace the finisher main PWB and check
for correct operation.
8910 Backup memory data problem
(optional 3000-sheet document fin-
isher)
Read and write data does not match.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
punch PWB and the connector YC4 on the
finisher main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Defective punch
PWB.
Replace the punch PWB and check for cor-
rect operation.
8920 Backup memory data problem
(optional mailbox of 3000-sheet docu-
ment finisher)
Read and write data does not match.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
mailbox main PWB and the connector YC7
on the finisher main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Defective mailbox
main PWB.
Replace the mailbox main PWB and check
for correct operation.
8930 Backup memory data problem
(optional centerfold unit of 3000-sheet
document finisher)
Read and write data does not match.
Poor contact in the
connector termi-
nals.
Check the connection of connector on the
centerfold main PWB and the connector
YC5 on the finisher main PWB, and the con-
tinuity across the connector terminals.
Repair or replace if necessary.
Defective center-
fold main PWB.
Replace the centerfold main PWB and
check for correct operation.
F000 Operation panel PWB communication
error
Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Defective opera-
tion panel PWB.
Replace the operation panel PWB and
check for correct operation.
F010 Main PWB checksum error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
F020 Memory checksum error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Defective expan-
sion memory.
Replace the expansion memory and check
for correct operation.
F030 Main PWB system error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
F040 Engine PWB communication error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
F226 VIDEO output error Defective main
PWB.
Replace the main PWB and check for cor-
rect operation.
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
