Kyocera KM-2530

2DF
2-3-3
Terminals (CN) Voltage Remarks
TB-1 TB-2 120V AC 120 V AC supply, input
TB-1 TB-2 220-240 V AC 220-240 V AC supply, input
1-1 1-2 24 V DC 24 V DC supply for SSW1, output
1-5 1-2 5 V DC 5 V DC supply for MPCB, output
1-6 1-2 24 V DC 24 V DC supply for MPCB, output
2-1 2-2 0 - 5 V DC Heater current monitor signal, output
2-3 2-2 0/5 V DC FH-S on/off, input
2-4 2-2 0/5 V DC FH-M on/off, input
2-5 2-2 5 V DC 5 V DC supply from MPCB, input
2-6 2-2 0/5 V DC (pulse) Zero-cross signal, input
2-7 2-2 0/5 V DC CFM5 remote signal, input
2-8 2-2 0/5 V DC SLEEP singal, input
3-1 3-5 24 V DC 24 V DC supply for finisher*, output
3-2 3-6 24 V DC 24 V DC supply for finisher*, output
3-3 3-7 24 V DC 24 V DC supply for finisher*, output
3-4 3-8 24 V DC 24 V DC supply for finisher*, output
3-9 3-10 5 V DC 5 V DC supply for finisher*, output
3-11 3-12 5 V DC 5 V DC supply for large paper deck*/paper feed desk*, output
3-14 3-13 24 V DC 24 V DC supply for large paper deck*/paper feed desk*, output
3-15 3-18 24 V DC 24 V DC supply for mailbox*, output
3-16 3-19 24 V DC 24 V DC supply for mailbox*, output
3-17 3-20 5 V DC 5 V DC supply for mailbox*, output
4-1 6-1 0/24 V DC CFM5 on/off, output
4-2 6-1 24 V DC 24 V DC supply for CFM5, output
5-1 5-3 120/0 V AC FH-M on/off, output
5-1 5-3 220-240/0 V AC FH-M on/off, output
5-2 5-3 120/0 V AC FH-S on/off, output
5-2 5-3 220-240/0 V AC FH-S on/off, output
6-2 6-1 24 V DC 24 V DC supply for SDPCB, output
6-4 6-3 5 V DC 5 V DC supply for SDPCB, output
6-5 6-7 24 V DC 24 V DC supply for STDF*/SRDF*, output
6-6 6-8 24 V DC 24 V DC supply for STDF*/SRDF*, output
6-9 6-11 5 V DC 5 V DC supply for STDF*/SRDF*, output
6-10 6-12 5 V DC 5 V DC supply for STDF*/SRDF*, output
9-1 TB-2 120 V AC 120 V AC supply for MSW, output
9-1 TB-2 220-240 V AC 220-240 V AC supply for MSW, output
*Optional.
