Kyocera KM-2530

2DF
2-4-15
Maintenance parts list
Maintenance part name
Part No. Fig. No. Ref. No.
Name used in service manual Name used in parts list
Upper/lower paper feed pulley PULLEY, PAPER FEED 2AR07220 4 4
Upper/lower separation pulley PULLEY, SEPARATION 2AR07230 4 5
Upper/lower fowarding pulley PULLEY, LEADING FEED 2AR07240 4 6
Bypass paper feed pulley UPPER PULLEY, BYPASS 61706770 10 29
Bypass separation pulley PULLEY, SEPARATION 2AR07230 10 20
Bypass forwarding pulley PULLEY, LEADING FEED 2AR07240 10 34
Bypass feed roller 1 ROLLER2 BYPASSFEED 2BL06540 11 11
Bypass feed roller 2 ROLLER4 BYPASSFEED 2BL06560 11 12
Left registration roller ROLLER REGIST L 2BL16021 7 11
Right registration roller RIGHT ROLLER REGIST 2BL06270 5 51
Feed pulley PULLEY FEED 2BL16080 6,7 37,8
Feed roller 1 PULLEY FEED 2BL06930 5 59
Feed roller 2 ROLLER B FEED 2BL06080 5 5
Feed roller 3 ROLLER C FEED 2BL06090 5 6
Registration switch SWITCH REGISTRATION 2BL27420 5 32
Contact glass CONTACT GLASS 35912010 9 46
Slit glass CONTACT GLASS, ADF 2AV12250 9 19
Mirror 1 MIRROR A 2AV12150 9 9
Mirror 2 and mirror 3 MIRROR B 2AV12160 9 10
Exposure lamp LAMP, SCANNER 2AV12100 9 4
Original size detection switvh SENSOR, ORIGINAL 35927290 9 53
Transfer roller unit TR-700 TRANSFER ASS’Y 5PLPXHLAPKX 725
Developing unit DEVELOPER ASS’Y 2BJ93010 13 1
Drum unit DRUM ASS’Y 2BJ93020 15 1
Main charger unit MC ASS’Y 2BL93090 15 48
Fixing unit FIXING ASS’Y 120 2BJ93040 14 -
FIXING ASS’Y 230 2BJ93050 14 -
Press roller separation claw CLAW, PRESS ROLLER 2BL20350 6 8
Eject roller ROLLER EXIT 2BL21020 8 4
Switchback roller ROLLER FEED SHIFT 2BL21030 8 3
Eject pulley PULLEY EXIT B 2BL21520 8 37
Switchback pulley PULLEY FEED SHIFT 2BL21330 6 2
