2DF
1-3-43
1-3-11 Installing the Printing System (option)
Procedure
1. Remove 2 screws and take off the cover.
Figure 1-3-88
Figure 1-3-89
2. Push the printing system all the way in along
the rails, and fasten it with 2 screws.
Install the (optional) network printer board.
3. Remove 2 screws and take off the cover.
4. Push the network printer board all the way in
along the rails, and fasten it with 2 screws.
Figure 1-3-87
Screws
Cover
Screws
Printing system
Cover
Screws
Netwark
printer
board
Screws
To Next Page
