Kyocera KM-2530

2DF
2-4-16
Periodic maintenance procedures
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Test copy and Perform at the maximum Test copy Every service
test print copy size
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Paper feed Upper/lower paper feed Replace Every service Replace. 1-6-3
section pulley
Upper/lower separation Replace Every service Replace. 1-6-3
pulley
Upper/lower forwarding Replace Every service Replace. 1-6-3
pulley
Bypass paper feed pulley Replace Every service Replace. 1-6-5
Bypass separation pulley Replace Every service Replace. 1-6-5
Bypass forwarding pulley Replace Every service Replace. 1-6-5
Bypass feed roller 1 Clean Every service Clean with alcohol or a dry cloth.
Bypass feed roller 2 Clean Every service Clean with alcohol or a dry cloth.
Left registration roller Clean Every service Clean with alcohol or a dry cloth.
Right registration roller Clean Every service Clean with alcohol or a dry cloth.
Feed pulley Clean Every service Clean with alcohol or a dry cloth.
Feed roller 1 Clean Every service Clean with alcohol or a dry cloth.
Feed roller 2 Clean Every service Clean with alcohol or a dry cloth.
Feed roller 3 Clean Every service Clean with alcohol or a dry cloth.
Registration switch Clean Every service Clean with a dry cloth.
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Optical section Slit glass Clean Every service Clean with alcohol and then
a dry cloth.
Contact glass Clean Every service Clean with alcohol and then
a dry cloth.
Mirror 1 Clean Every service Clean with alcohol and then
a dry cloth only if vertical black
lines appear on the copy image.
Mirror 2 and mirror 3 Clean Every service Clean with alcohol and then
a dry cloth only if vertical black
lines appear on the copy image.
Lens Clean Every service Clean with a dry cloth only if
vertical black lines appear on
the copy image.
Reflector Clean Every service Clean with a dry cloth only if
vertical black lines appear on
the copy image.
Exposure lamp Clean or replace Every service Replace if an image problem
occurs.
Optical rail Grease Every service Check noise and shifting and
then apply scanner rail grease
PG671.
Original size detection Clean Every service Clean the sensor emitter and
sensor receiver with alcohol or a dry
cloth only if there is a problem.
