2DF
2-3-7
Terminals (CN) Voltage Remarks
1-1 1-7 0/5 V DC SLEEP signal, output
1-2 1-7 0/5 V DC CFM5 remote signal, output
1-3 1-7 0/5 V DC (pulse) Zero-cross signal, input
1-4 1-7 5 V DC 5V DC supply for PSPCB, output
1-5 1-7 0/5 V DC FH-M on/off, output
1-6 1-7 0/5 V DC FH-S on/off, output
1-8 1-7 0 - 5 V DC Heater current monitor signal, input
2-1 2-2 24 V DC 24 V DC supply from SSW2, input
2-5 2-2 5 V DC 5 V DC supply from PSPCB, input
2-6 2-2 24 V DC 24 V DC supply from PSPCB, input
3-A1 3-A2 0/5 V DC (pulse) Serial signal for mailbox*, input
3-A3 3-A4 0/5 V DC (pulse) Serial signal from mailbox*, output
3-A5 3-A4 0/5 V DC Mailbox* connection signal, input
3-A6 3-A4 0/5 V DC RESET signal for mailbox*, output
3-B1 3-B2 0/5 V DC (pulse) Serial signal for large paper deck*/paper feed desk*, output
3-B3 3-B4 0/5 V DC (pulse) Serial signal from large paper deck*/paper feed desk*, input
3-B5 3-B4 0/5 V DC FSW on/off signal from large paper deck*/paper feed desk*, input
3-B6 3-B4 0/5 V DC RESET signal for large paper deck*/paper feed desk*, output
4-1 4-2 0/5 V DC (pulse) Serial signal from finisher*, input
4-3 4-4 0/5 V DC (pulse) Serial signal for finisher*, output
5-1 4-4 0/5 V DC RESET signal for finisher*, output
5-2 4-4 0/5 V DC Finisher* connection signal, input
6-A1 6-A4 0/5 V DC BYPPWSW paper width detection signal, input
6-A2 6-A4 0/5 V DC BYPPWSW paper width detection signal, input
6-A3 6-A4 0/5 V DC BYPPWSW paper width detection signal, input
6-A5 6-A4 5 V DC 5 V DC supply for BYPPSW, output
6-A6 6-A4 0/5 V DC BYPPSW on/off, input
6-A8 6-A7 24 V DC 24 V DC supply for BYPPFCL, output
6-A9 6-A7 0/24 V DC BYPPFCL on/off, output
6-A10 6-A7 24 V DC 24 V DC supply for BYPFCL, output
6-A11 6-A7 0/24 V DC BYPFCL on/off, output
6-B1 6-B3 5 V DC 5 V DC supply for OFS, output
6-B2 6-B3 0/5 V DC OFS on/off, input
6-B4 6-B5 0/5 V DC TDDSW on/off, input
6-B6 6-B7 0/5 V DC FRCSW on/off, input
6-B8 6-B9 0/24V DC CFM3 on/off, output
6-B10 6-B12 5 V DC 5 V DC supply for BYPPLSW, output
6-B11 6-B12 0/5 V DC BYPPLSW on/off, input
7-1 7-3 0 - 5 V DC Developing bias control voltage, output
7-2 7-3 24 V DC 24 V DC supply for HVTPCB, output
7-4 7-3 0/5 V DC Main charging on/off, output
7-5 7-3 0/5 V DC (pulse) Developing bias CLOCK signal, output
7-6 7-3 0/5 V DC Separation charging on/off, output
7-7 7-3 0 - 5 V DC Separation charging control voltage, output
7-8 7-3 0 - 5 V DC Transfer charging control voltage, output
7-9 7-3 0 - 5 V DC Transfer limit voltage, output
7-10 7-3 0/5 V DC Transfer charging on/off, output
7-11 7-3 0/5 V DC Transfer reverse bias remote signal, output
7-12 7-3 0/5 V DC Transfer forward bias remote signal, output
7-13 7-3 0/5 V DC Transfer current detection signal, input
7-14 7-3 0/5 V DC Transfer current detection signal, input
8-1 8-7 5 V DC 5 V DC supply for LSU, output
8-2 8-7 0/5 V DC LSU SAMPLE signal, output
8-3 8-7 0/5 V DC LSU POWCONT signal, output
8-4 8-7 0/5 V DC LSU LASER signal, output
8-5 8-7 0/5 V DC LSU VIDEO + signal, output
*Optional.
