Kyocera KM-2530

2DF
2-3-12
Terminals (CN) Voltage Remarks
43-A6 43-A2 5/0 V DC (pulse) Printer board* SO signal, input
43-A7 43-A2 5/0 V DC (pulse) Printer board* RESET signal, output
43-A8 43-A2 5/0 V DC (pulse) Printer board* PDOUT signal, output
43-A10 43-A2 5/0 V DC (pulse) Printer board* VDATAP signal, input
43-A12 43-A2 5/0 V DC (pulse) Printer board* VDATAN signal, input
43-A14 43-A2 5/0 V DC (pulse) Printer board* FPCLKsignal, output
43-A15 43-A2 5/0 V DC (pulse) Printer board* FPDAT signal, input
43-A17 43-A2 5/0 V DC (pulse) Printer board* VDATA signal, input
43-B1 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B2 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B3 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B4 43-A2 5/0 V DC (pulse) Printer board* SDIR signal, output
43-B5 43-A2 5/0 V DC (pulse) Printer board* ESGIR signal, output
43-B6 43-A2 5/0 V DC (pulse) Printer board* VDFON signal, output
43-B7 43-A2 5/0 V DC (pulse) Printer board* VSREQN signal, output
43-B12 43-A2 5/0 V DC (pulse) Printer board* FPDIR signal, output
43-B13 43-A2 5/0 V DC (pulse) Printer board* FPPOWER signal, output
43-B15 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B16 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B17 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B18 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B19 43-A2 5 V DC Printer board* 5 V DC supply, output
43-B20 43-A2 5 V DC Printer board* 5 V DC supply, output
44-1 44-2 3.3 V DC Fax board* 3.3 V DC supply, output
44-3 44-4 5/0 V DC (pulse) Fax board* FPVCLK signal, output
44-5 44-6 5/0 V DC (pulse) Fax board* FVCLK signal, input
44-7 44-8 5/0 V DC (pulse) Fax board* FMRE signal, input
44-9 44-10 5/0 V DC (pulse) Fax board* /FPVD signal, input
44-11 44-12 5/0 V DC (pulse) Fax board* /FPHSYNC signal, output
44-13 44-14 5/0 V DC (pulse) Fax board* /FPVSYNC signal, output
44-15 44-16 5/0 V DC (pulse) Fax board* /FOVSYNC signal, output
44-17 44-18 5/0 V DC (pulse) Fax board* /FOHSTHIN signal, output
44-19 44-20 5/0 V DC (pulse) Fax board* FMIPOUTO signal, output
44-21 44-22 5/0 V DC (pulse) Fax board* FMREOUT signal, output
44-23 44-24 5/0 V DC (pulse) Fax board* FFOCLK signal, output
44-25 44-26 5/0 V DC (pulse) Fax board* /MMISTS signal, output
44-27 44-28 Analog Fax board* FMMI_TXD2 signal, output
44-29 44-30 Analog Fax board* FMMI_RXD2 signal, input
44-31 44-30 5/0 V DC (pulse) Fax board* /FAXRESET signal, output
44-32 44-30 5/0 V DC (pulse) Fax board* /FAXREADY signal, input
44-33 44-30 5/0 V DC (pulse) Fax board* /PREQ signal, input
44-34 44-30 5/0 V DC (pulse) Fax board* /SREQ signal, input
44-35 44-30 5/0 V DC (pulse) Fax board* /SETFAX signal, input
44-36 44-30 5/0 V DC (pulse) Fax board* /MAINSTS signal, output
44-38 44-37 Analog Fax board* FMAIN_TXD0 signal, output
44-40 44-39 Analog Fax board* FMAIN_RXD0 signal, input
