2DF
2-3-16
Terminals (CN) Voltage Remarks
1-1 3-14 0/5 V DC OPCB-L DIGKEY1 signal, output
1-2 3-14 0/5 V DC OPCB-L DIGKEY2 signal, output
1-3 3-14 0/5 V DC OPCB-L DIGKEY3 signal, output
1-4 3-14 0/5 V DC (pulse) OPCB-L SCAN1 signal, input
1-5 3-14 0/5 V DC (pulse) OPCB-L SCAN2 signal, input
1-6 3-14 0/5 V DC (pulse) OPCB-L SCAN3 signal, input
1-7 3-14 0/5 V DC (pulse) OPCB-L SCAN4 signal, input
1-8 3-14 0/5 V DC (pulse) OPCB-L DIGLED1 signal, input
1-9 3-14 0/5 V DC (pulse) OPCB-L DIGLED2 signal, input
1-10 3-14 0/5 V DC (pulse) OPCB-L DIGLED3 signal, input
1-11 3-14 0/5 V DC (pulse) OPCB-L DIGLED4 signal, input
1-12 3-14 0/5 V DC (pulse) OPCB-L DIGLED5 signal, input
1-13 3-14 0/5 V DC (pulse) OPCB-L DIGLED6 signal, input
2-1 3-14 0/5 V DC LCD VEE signal, input
2-2 3-14 0/5 V DC (pulse) LCD D3 data, input
2-3 3-14 0/5 V DC (pulse) LCD D2 data, input
2-4 3-14 0/5 V DC (pulse) LCD D1 data, input
2-5 3-14 0/5 V DC (pulse) LCD D0 data, input
2-6 3-14 0/5 V DC LCD DISPLAY signal, input
2-7 3-14 GND LCD VSS signal, input
2-8 3-14 5 V DC LCD VDD signal, input
2-9 3-14 GND LCD VSS signal, input
2-10 3-14 0/5 V DC (pulse) LCD CP signal, input
2-11 3-14 0/5 V DC (pulse) LCD LOAD signal, input
2-12 3-14 0/5 V DC (pulse) LCD FRAME signal, input
2-13 3-14 0/5 V DC (pulse) Touch panel detection voltage Y2, input
2-14 3-14 0/5 V DC (pulse) Touch panel detection voltage X2, input
2-15 3-14 0/5 V DC (pulse) Touch panel detection voltage Y1, output
2-16 3-14 0/5 V DC (pulse) Touch panel detection voltage X1, output
2-17 3-14 0/5 V DC (pulse) OPCB-L BUZZER signal, input
3-1 3-14 0/5 V DC OPCB-R DIGKEY4 signal, output
3-2 3-14 0/5 V DC OPCB-R DIGKEY5 signal, output
3-3 3-14 0/5 V DC OPCB-R DIGKEY6 signal, output
3-4 3-14 0/5 V DC OPCB-R DIGKEY7 signal, output
3-5 3-14 0/5 V DC OPCB-R DIGKEY8 signal, output
3-6 3-14 0/5 V DC OPCB-R DIGKEY9 signal, output
3-7 3-14 0/5 V DC (pulse) OPCB-R SCAN5 signal, input
3-8 3-14 0/5 V DC (pulse) OPCB-R SCAN6 signal, input
3-9 3-14 0/5 V DC (pulse) OPCB-R SCAN7 signal, input
3-10 3-14 0/5 V DC (pulse) OPCB-R SCAN8 signal, input
3-11 3-14 0/5 V DC (pulse) OPCB-R DIGLED7 signal, input
3-12 3-14 0/5 V DC (pulse) OPCB-R DIGLED8 signal, input
3-13 3-14 5 V DC 5 V DC supply for OPCB-R, input
3-15 3-14 0/5 V DC OPCB-R LAMP OFF signal, input
3-16 3-17 24 V DC 24 V DC supply for OPCB-R, input
4-1 3-14 0/5 V DC (pulse) Touch panel detection voltage Y2, output
4-2 3-14 0/5 V DC (pulse) Touch panel detection voltage X2, output
4-3 3-14 0/5 V DC (pulse) Touch panel detection voltage Y1, input
4-4 3-14 0/5 V DC (pulse) Touch panel detection voltage X1, input
5-1 3-14 0/5 V DC (pulse) LCD FRAME signal, output
5-2 3-14 0/5 V DC (pulse) LCD LOAD signal, output
5-3 3-14 0/5 V DC (pulse) LCD CP signal, output
5-4 3-14 GND LCD VSS signal, output
5-5 3-14 5 V DC LCD VDD signal, output
5-6 3-14 GND LCD VSS signal, output
5-7 3-14 Analog LCD control signal, output
