2DF
1-3-42
Figure 1-3-79
Figure 1-3-80
• If the printing system was installed
27. Reinstall the printing system into the shield
cover, fastening it into place with 2 screws.
Screws
Printing system
Rear cover
Screws
28. Reattach the rear cover with 13 screws.
29. Adhere the certification labels to the rear
cover at the locations indicated in the
illustration (only 120 V Spac.).
Figure 1-3-81
Certification
labels
1-3-40
