CHAPTER 8 WHEN A PROBLEM OCCURS
8-5
Remove the misfed paper.
When the duplex unit is installed, raise the duplex unit
to remove the misfed paper.
Remove the misfed paper in the output section.
Close the left cover 1.
2
3
4
5
•
Misfeed in left cover 1 (JAM 35)
If the message below appears, a misfeed has occurred in the
left cover 1. Remove the misfed paper using the procedure given
below.
Pull up the lock lever to open the left cover 1.
Remove the misfed paper.
When the duplex unit is installed, raise the duplex unit
to remove the misfed paper.
Remove the misfed paper in the output section.
1
Inch specifications
Metric specifications
2
3
4
CAUTION
The copier’s fixing unit is extremely hot. Take sufficient
care when working in this area, as there is a danger of
getting burned.
To Next Page
