CHAPTER 9 CLEANING AND SPECIFICATIONS
9-2
Pull up the lock lever to open the left cover 1.
Clean the separator by moving the cleaning brush from
left to right several times along with the separator.
Close the left cover 1.
• Cleaning the transfer roller
Open the front cover.
Remove the cleaning brush.
3
4
5
Pull up the lock lever to open the left cover 1.
While rotating the gear as shown, clean the transfer roller
by moving the cleaning brush from left to right along with
the transfer roller.
Close the left cover 1.
4
5
3
1
2
To Next Page
