Kyocera KM-3035

2FD/2FF/2FG
1-4-19
Maintenance
Description
item No.
U030 Checking motor operation
Description
Drives each motor.
Purpose
To check the operation of each motor.
Method
1. Press the start key. The screen for selecting an item is displayed.
2. Select the motor to be operated. The selected item is displayed in reverse and the operation starts.
Display Operation
FEED Paper feed motor operates
MAIN Drive motor operates
EJECT(FW) Eject motor rotates forward
EJECT(REV) Eject motor rotates in reverse
3. To stop operation, press the stop/clear key.
Completion
Press the stop key after operation stops. The screen for selecting a maintenance item No. is displayed.
U031 Checking switches for paper conveying
Description
Displays the on-off status of each paper detection switch on the paper path.
Purpose
To check if the switches for paper conveying operate correctly.
Method
1. Press the start key. A list of the switches, the on-off status of which can be checked, are displayed.
2. Turn each switch on and off manually to check the status.
When the on-status of a switch is detected, that switch is displayed in reverse.
Display Switches
F1 Feed switch 1 (FSW1)
F2 Feed switch 2 (FSW2)
F3 Feed switch 3 (FSW3)
BYP Bypass feed switch (BYPFSW)
RES Registration switch (RSW)
EJE Eject switch (ESW)
BRA Feedshift switch (FSSW)
DUP Duplex paper conveying switch (DUPPCSW)
JOB Job separator eject switch (JBESW)*
*Optional.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
