Kyocera KM-3035

2FD/2FF/2FG
2-4-16
Periodic maintenance procedures
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Test copy and Perform at the maximum Test copy Every service
test print copy size
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Paper feed Upper/lower paper feed Replace 400K (30)/500K (40/50) Replace.* 1-6-3
section pulley
Upper/lower separation Replace 400K (30)/500K (40/50) Replace.* 1-6-3
pulley
Upper/lower forwarding Replace 400K (30)/500K (40/50) Replace.* 1-6-3
pulley
Bypass paper feed pulley Replace 400K (30)/500K (40/50) Replace.* 1-6-5
Bypass separation pulley Replace 400K (30)/500K (40/50) Replace. * 1-6-5
Bypass forwarding pulley Replace 400K (30)/500K (40/50) Replace. * 1-6-5
Bypass feed roller 1 Clean 400K (30)/500K (40/50) Clean with alcohol.*
Bypass feed roller 2 Clean 400K (30)/500K (40/50) Clean with alcohol.*
Left registration roller Clean 400K (30)/500K (40/50) Clean with alcohol.*
Right registration roller Clean 400K (30)/500K (40/50) Clean with alcohol.*
Feed pulley Clean 400K (30)/500K (40/50) Clean with alcohol.*
Feed roller 1 Clean 400K (30)/500K (40/50) Clean with alcohol.*
Feed roller 2 Clean 400K (30)/500K (40/50) Clean with alcohol.*
Feed roller 3 Clean 400K (30)/500K (40/50) Clean with alcohol.*
Registration switch Clean 400K (30)/500K (40/50) Clean with a dry cloth.
Lower regist cleaner Replace 400K (30)/500K (40/50) Replace.
Registration guide Replace 400K (30)/500K (40/50) Replace.
Maintenance
Section
part/location
Method Maintenance cycle Points and cautions Page
Optical section Slit glass Clean 400K (30)/500K (40/50) Clean with a dry cloth.
Contact glass Clean 400K (30)/500K (40/50) Clean with alcohol and then
a dry cloth.
Mirror 1 Clean User call Clean with alcohol and then
a dry cloth only if vertical black
lines appear on the copy image.
Mirror 2 and mirror 3 Clean User call Clean with alcohol and then
a dry cloth only if vertical black
lines appear on the copy image.
Lens Clean User call Clean with a dry cloth only if
vertical black lines appear on
the copy image.
Reflector Clean User call Clean with a dry cloth only if
vertical black lines appear on
the copy image.
Exposure lamp Clean or replace User call Replace if an image problem
occurs.
Optical rail Grease User call Check noise and shifting and
then apply scanner rail grease
PG671.
Original size detection Clean User call Clean the sensor emitter and
sensor receiver with alcohol or a
dry cloth only if there is a problem.
*Check and clean with alcohol when user call occurs.
