Kyocera KM-3035

2FD/2FF/2FG
1-3-58
1-3-15 Installing the 1000-sheet finisher (option)
Procedure
1. Open the left cover of the copier.
2. Remove the two screws securing the
feedshift guide assembly and then the
assembly.
Figure 1-3-136
Screws
Feedshift guide
assembly
Left cover
3. Fit the curl eliminator to the left cover such
that the projections on the cover fit into the
two ends of the curl eliminator.
4. Secure the curl eliminator using the two
screws removed in step 2.
8
Screw
Screw
Projection
Projection
Curl eliminator
Figure 1-3-137
5. Close the left cover.
6. Fit the latch catch to the left cover using two
M4 × 10 binding screws.
Left cover
Latch catch
M4 × 10 binding screws
Figure 1-3-138
