2A3/4
3-6-56
Terminals (CN) Voltage Remarks
13A-7 5-16 0/5 V DC SBFSSOL on/off, output
13A-9 5-16 0/5 V DC OFSOL release signal, output
13A-10 5-16 0/5 V DC OFSOL latch-on signal, output
13A-11 5-16 0/5 V DC OFM enable signal, output
13B-1 5-16 0/5 V DC OFM control signal OFM RET, output
13B-2 5-16 0/5 V DC (pulse) OFM drive clock pulse, output
13B-3 5-16 0/5 V DC OFM rotation direction switching signal
OFM CWB, output
13B-4 5-16 0/5 V DC OCM enable signal, output
13B-5 5-16 0/5 V DC OCM control signal OCM RET, output
13B-6 5-16 0/5 V DC (pulse) OCM drive clock pulse, output
13B-7 5-16 0/5 V DC OCM rotation direction switching signal
OCM CWB, output
13B-8 5-16 OCM current control voltage OCM Vref,
output
13B-9 5-16 0/5 V DC OCM drive control signal OCM M3, output
13B-10 5-16 0/5 V DC OCM drive control signal OCM M2, output
13B-11 5-16 0/5 V DC OCM drive control signal OCM M1, output
14-1 5-16 0/5 V DC OSBSW on/off, input
14-2 5-16 0/5 V DC OFSW on/off, input
14-3 5-16 0/5 V DC OSSW on/off, input
14-6 5-16 0/5 V DC SRDF installed/not installed signal, input
14-7 5-16 0/5 V DC OSWSW on/off, input
14-8 5-16 5/0 V DC DFSSW2 off/on, input
14-9 5-16 5/0 V DC DFSSW1 off/on, input
14-10 5-16 5/0 V DC OSLSW off/on, input
14-11 5-16 5/0 V DC DFTSW off/on, input
