Kyocera KM-8030

2FB/2FC
2-3-10
Connector Pin No. Signal I/O Voltage Description
YC1 1 EG_DATA I 0/5 V DC LSU data signal
Connected
to the
engine PWB
2 EG_CLK I 0/5 V DC
(pulse)
LSU clock signal
3 EG_LOAD I 0/5 V DC LSU load signal
4 LDON I 0/5 V DC LDON signal
5 SGND - - Signal ground
6 SGND - - Signal ground
7 LSU_5V I 5 V DC 5 V DC power input
8 PVSYNC I 0/5 V DC PVSYNC signal
9 OUTPEN I 0/5 V DC OUTPEN signal
10 EGIRN I 0/5 V DC Engine PWB IRN signal
11 EGSDIR I 0/5 V DC Engine PWB SDIR signal
12 EGSBSY I 0/5 V DC Engine PWB SBSY signal
13 EGSO I 0/5 V DC
(pulse)
Engine PWB serial communication signal
14 EGSI O 0/5 V DC
(pulse)
Engine PWB serial communication signal
15 EGSCKN O 0/5 V DC
(pulse)
Engine PWB clock signal
YC2
1 SCSCKN O 0/5 V DC
(pulse)
Scanner clock signal
Connected
to the scan-
ner PWB
2 SCSI O 0/5 V DC
(pulse)
Scanner serial communication signal
3 SCSO I 0/5 V DC
(pulse)
Scanner serial communication signal
4 SCSBSY I 0/5 V DC Scanner SBSY signal
5 SCSDIR I 0/5 V DC Scanner SDIR signal
6 SCIRN I 0/5 V DC Scanner IRN signal
7 SGND - - Signal ground
8 SCANNER SET I 0/5 V DC Scanner set signal
YC4
A1 WINCD_DIN_R
P3
I 0/3.3 V DC
(pulse)
Image data signal
Connected
to the SHD
PWB
A2 WINCD_DIN_R
N3
I 0/3.3 V DC
(pulse)
Image data signal
A3 WINCD_DIN_R
P2
I 0/3.3 V DC
(pulse)
Image data signal
A4 WINCD_DIN_R
N2
I 0/3.3 V DC
(pulse)
Image data signal
A5 WINCD_DIN_R
P1
I 0/3.3 V DC
(pulse)
Image data signal
A6 WINCD_DIN_R
N1
I 0/3.3 V DC
(pulse)
Image data signal
A7 WINCD_DIN_R
P0
I 0/3.3 V DC
(pulse)
Image data signal
A8 WINCD_DIN_R
N0
I 0/3.3 V DC
(pulse)
Image data signal
A9 WINCD_DIN_G
P3
I 0/3.3 V DC
(pulse)
Image data signal
A10 WINCD_DIN_G
N3
I 0/3.3 V DC
(pulse)
Image data signal
A11 WINCD_DIN_G
P2
I 0/3.3 V DC
(pulse)
Image data signal
A12 WINCD_DIN_G
N2
I 0/3.3 V DC
(pulse)
Image data signal
A13 WINCD_DIN_G
P1
I 0/3.3 V DC
(pulse)
Image data signal
A14 WINCD_DIN_G
N1
I 0/3.3 V DC
(pulse)
Image data signal
