Kyocera KM-8030

2FB/2FC
2-3-11
YC4
A15 WINCD_DIN_G
P0
I 0/3.3 V DC
(pulse)
Image data signal
Connected
to the SHD
PWB
A16 WINCD_DIN_G
N0
I 0/3.3 V DC
(pulse)
Image data signal
A17 SGND - - Signal ground
A18 SGND - - Signal ground
A19 SGND - - Signal ground
A20 SGND - - Signal ground
A21 SGND - - Signal ground
A22 SGND - - Signal ground
A23 SGND - - Signal ground
A24 SGND - - Signal ground
A25 N.C - - Not used
A26 N.C - - Not used
A27 SGND - - Signal ground
A28 SGND - - Signal ground
A29 WINCDVSY I 0/3.3 V DC CCD VSYNC signal
A30 SGND - - Signal ground
A31 N.C - - Not used
A32 N.C - - Not used
A33 N.C - - Not used
A34 N.C - - Not used
B1 WINCD_DIN_R
P7
I 0/3.3 V DC
(pulse)
Image data signal
B2 WINCD_DIN_R
N7
I 0/3.3 V DC
(pulse)
Image data signal
B3 WINCD_DIN_R
P6
I 0/3.3 V DC
(pulse)
Image data signal
B4 WINCD_DIN_R
N6
I 0/3.3 V DC
(pulse)
Image data signal
B5 WINCD_DIN_R
P5
I 0/3.3 V DC
(pulse)
Image data signal
B6 WINCD_DIN_R
N5
I 0/3.3 V DC
(pulse)
Image data signal
B7 WINCD_DIN_R
P4
I 0/3.3 V DC
(pulse)
Image data signal
B8 WINCD_DIN_R
N4
I 0/3.3 V DC
(pulse)
Image data signal
B9 WINCD_DIN_G
P7
I 0/3.3 V DC
(pulse)
Image data signal
B10 WINCD_DIN_G
N7
I 0/3.3 V DC
(pulse)
Image data signal
B11 WINCD_DIN_G
P6
I 0/3.3 V DC
(pulse)
Image data signal
B12 WINCD_DIN_G
N6
I 0/3.3 V DC
(pulse)
Image data signal
B13 WINCD_DIN_G
P5
I 0/3.3 V DC
(pulse)
Image data signal
B14 WINCD_DIN_G
N5
I 0/3.3 V DC
(pulse)
Image data signal
B15 WINCD_DIN_G
P4
I 0/3.3 V DC
(pulse)
Image data signal
B16 WINCD_DIN_G
N4
I 0/3.3 V DC
(pulse)
Image data signal
B17 SGND - - Signal ground
B18 SGND - - Signal ground
B19 SGND - - Signal ground
B20 SGND - - Signal ground
Connector Pin No. Signal I/O Voltage Description
