YC4 B21 SGND - - Signal ground
Connected
to the SHD
PWB
B22 SGND - - Signal ground
B23 SGND - - Signal ground
B24 SGND - - Signal ground
B25 WINCDCK_P I 0/3.3 V DC
(pulse)
CCD clock signal
B26 WINCDCK_N I 0/3.3 V DC
(pulse)
CCD clock signal
B27 WINCDHSY_P I 0/3.3 V DC CCD HSYNC signal
B28 WINCDHSY_N I 0/3.3 V DC CCD HSYNC signal
B29 WINCDMRE_P I 0/3.3 V DC CCD MRE signal
B30 WINCDMRE_N I 0/3.3 V DC CCD MRE signal
B31 N.C - - Not used
B32 N.C - - Not used
B33 N.C - - Not used
B34 N.C - - Not used
YC5
A1 WINCS_DIN_R
P7
I 0/3.3 V DC
(pulse)
Image data signal
Connected
to the DP
main PWB
A2 WINCS_DIN_R
N7
I 0/3.3 V DC
(pulse)
Image data signal
A3 WINCS_DIN_R
P6
I 0/3.3 V DC
(pulse)
Image data signal
A4 WINCS_DIN_R
N6
I 0/3.3 V DC
(pulse)
Image data signal
A5 WINCS_DIN_R
P5
I 0/3.3 V DC
(pulse)
Image data signal
A6 WINCS_DIN_R
N5
I 0/3.3 V DC
(pulse)
Image data signal
A7 WINCS_DIN_R
P4
I 0/3.3 V DC
(pulse)
Image data signal
A8 WINCS_DIN_R
N4
I 0/3.3 V DC
(pulse)
Image data signal
A9 WINCS_DIN_G
P7
I 0/3.3 V DC
(pulse)
Image data signal
A10 WINCS_DIN_G
N7
I 0/3.3 V DC
(pulse)
Image data signal
A11 WINCS_DIN_G
P6
I 0/3.3 V DC
(pulse)
Image data signal
A12 WINCS_DIN_G
N6
I 0/3.3 V DC
(pulse)
Image data signal
A13 WINCS_DIN_G
P5
I 0/3.3 V DC
(pulse)
Image data signal
A14 WINCS_DIN_G
N5
I 0/3.3 V DC
(pulse)
Image data signal
A15 WINCS_DIN_G
P4
I 0/3.3 V DC
(pulse)
Image data signal
A16 WINCS_DIN_G
N4
I 0/3.3 V DC
(pulse)
Image data signal
A17 SGND - - Signal ground
A18 SGND - - Signal ground
A19 SGND - - Signal ground
A20 SGND - - Signal ground
A21 SGND - - Signal ground
A22 SGND - - Signal ground
A23 SGND - - Signal ground
A24 SGND - - Signal ground
A25 WINCSCK_P I 0/3.3 V DC
(pulse)
CIS clock signal
Connector Pin No. Signal I/O Voltage Description
