YC17 1 R24V O 24 V DC 24 V DC power output
Connected
to the poly-
gon motor
2 PGND - - Power ground
3 PLG REM O 0/24 V DC Polygon motor: On/off
4 PLG READY I 0/5 V DC Polygon motor ready signal
5 PLG CLK O 0/5 V DC
(pulse)
Polygon motor clock signal
YC18 1 24V O 24 V DC 24 V DC power output
Connected
to the
optional key
counter
2 K.CARD REM O 0/24 V DC Key counter count signal
3 SET SIG I 0/5 V DC Key counter set signal
4 GND - - Signal ground
YC22 1 24V O 24 V DC 24 V DC power output
Connected
to the total
counter
2 REM O 0/24 V DC Total counter count signal
3 GND - - Signal ground
4 T COUNT SET I 0/5 V DC Total counter set signal
YC23
1 D TEMP SENS I Analog Developing humidity sensor temperature detection
signal
Connected
to the devel-
oping
humidity
sensor
2 SGND - - Signal ground
3 D HUMID
SENS
I Analog Developing humidity sensor humidity detection sig-
nal
4 5V O 5 V DC 5 V DC power output
Connector Pin No. Signal I/O Voltage Description
