Kyocera KM-8030

2FB/2FC
2-3-30
Connector Pin No. Signal I/O Voltage Description
YC1
1 ADCLK-A I 0/3.3 V DC
(pulse)
CCD A/D clock signal
Connected
to the SHD
PWB
2 RESETN-A I 0/3.3 V DC CCD reset signal
3 GND - - Signal ground
4 CCDA9 O 0/3.3 V DC
(pulse)
Image data signal
5 CCDA8 O 0/3.3 V DC
(pulse)
Image data signal
6 CCDA7 O 0/3.3 V DC
(pulse)
Image data signal
7 CCDA6 O 0/3.3 V DC
(pulse)
Image data signal
8 CCDA5 O 0/3.3 V DC
(pulse)
Image data signal
9 GND - - Signal ground
10 CCDA4 O 0/3.3 V DC
(pulse)
Image data signal
11 CCDA3 O 0/3.3 V DC
(pulse)
Image data signal
12 CCDA2 O 0/3.3 V DC
(pulse)
Image data signal
13 CCDA1 O 0/3.3 V DC
(pulse)
Image data signal
14 CCDA0 O 0/3.3 V DC
(pulse)
Image data signal
15 GND - - Signal ground
16 FESHD-A I 0/3.3 V DC
(pulse)
CCD SHD timing signal
17 FECP-A I 0/3.3 V DC
(pulse)
CCD CP timing signal
18 FESHP-A I 0/3.3 V DC
(pulse)
CCD SHP timing signal
19 GND - - Signal ground
20 GND - - Signal ground
21 GND - - Signal ground
22 GND - - Signal ground
23 3.3V O 3.3 V DC 3.3 V DC power output
24 3.3V O 3.3 V DC 3.3 V DC power output
25 3.3V O 3.3 V DC 3.3 V DC power output
26 3.3V O 3.3 V DC 3.3 V DC power output
YC2
1 ADCLK-B I 0/3.3 V DC
(pulse)
CCD A/D clock signal
Connected
to the SHD
PWB
2 RESETN-B I 0/3.3 V DC CCD reset signal
3 GND - - Signal ground
4 CCDC9 O 0/3.3 V DC
(pulse)
Image data signal
5 CCDC8 O 0/3.3 V DC
(pulse)
Image data signal
6 CCDC7 O 0/3.3 V DC
(pulse)
Image data signal
7 CCDC6 O 0/3.3 V DC
(pulse)
Image data signal
8 CCDC5 O 0/3.3 V DC
(pulse)
Image data signal
9 GND - - Signal ground
10 CCDC4 O 0/3.3 V DC
(pulse)
Image data signal
11 CCDC3 O 0/3.3 V DC
(pulse)
Image data signal
