Kyocera KM-8030

2FB/2FC
2-3-31
YC2
12 CCDC2 O 0/3.3 V DC
(pulse)
Image data signal
Connected
to the SHD
PWB
13 CCDC1 O 0/3.3 V DC
(pulse)
Image data signal
14 CCDC0 O 0/3.3 V DC
(pulse)
Image data signal
15 GND - - Signal ground
16 FESHD-B I 0/3.3 V DC
(pulse)
CCD SHD timing signal
17 FECP-B I 0/3.3 V DC
(pulse)
CCD CP timing signal
18 FESHP-B I 0/3.3 V DC
(pulse)
CCD SHP timing signal
19 GND - - Signal ground
20 GND - - Signal ground
21 GND - - Signal ground
22 GND - - Signal ground
23 12V O 12 V DC 12 V DC power output
24 12V O 12 V DC 12 V DC power output
25 12V O 12 V DC 12 V DC power output
26 12V O 12 V DC 12 V DC power output
YC3
1 1A-1 I 0/5 V DC
(pulse)
CCD clock 1A signal
Connected
to the SHD
PWB
2 2A-1 I 0/5 V DC
(pulse)
CCD clock 2A signal
3 1A-2 I 0/5 V DC
(pulse)
CCD clock 1A signal
4 2A-2 I 0/5 V DC
(pulse)
CCD clock 2A signal
5 GND - - Signal ground
6 GND - - Signal ground
7 GND - - Signal ground
8 GND - - Signal ground
9 2B0 I 0/5 V DC
(pulse)
CCD clock 2B signal
10 SH0 I 0/5 V DC
(pulse)
CCD clock SH signal
11 GND - - Signal ground
12 RS0 I 0/5 V DC
(pulse)
CCD clock RS signal
13 CP0 I 0/5 V DC
(pulse)
CCD clock CP signal
14 GND - - Signal ground
15 ISSCLKAFE I 0/5 V DC
(pulse)
CCD clock signal
16 ISSDIAFE I 0/5 V DC
(pulse)
CCD serial communication signal
17 ISSDOAFE O 0/5 V DC
(pulse)
CCD serial communication signal
18 ISSELAFE I 0/5 V DC CCD SEL signal
19 GND - - Signal ground
20 GND - - Signal ground
21 GND - - Signal ground
22 GND - - Signal ground
23 CLK5V O 5 V DC 5 V DC power output
24 CLK5V O 5 V DC 5 V DC power output
25 CLK5V O 5 V DC 5 V DC power output
26 CLK5V O 5 V DC 5 V DC power output
Connector Pin No. Signal I/O Voltage Description
