Kyocera KM-8030

2FB/2FC-2.0
2-3-35
YC5 A1 24V I 24 V DC 24 V DC power input
Connected
to the MP
tray unit
A2 MP SOL PUL O 0/24 V DC MP solenoid (activate): On/off
A3 MP SOL RTN O 0/24 V DC MP solenoid (return): On/off
A4 5V O 5 V DC 5 V DC power output
A5 MP PE SW I 0/5 V DC MP paper empty switch: On/off
A6 SGND - - Signal ground
A7 5V O 5 V DC 5 V DC power output
A8 CONT SENS I Analog Toner container detection signal
A9 SGND - - Signal ground
B1 SGND - - Signal ground
B2 MP DIG2 I 0/5 V DC MP paper width size switch: On/off
B3 MP DIG1 I 0/5 V DC MP paper width size switch: On/off
B4 MP DIG0 I 0/5 V DC MP paper width size switch: On/off
B5 MP PSD SW I 0/5 V DC MP paper length size switch: On/off
B6 SGND - - Signal ground
B7 SGND - - Signal ground
B8 MP TRY SW I 0/5 V DC MP tray switch: On/off
B9 5V O 5 V DC 5 V DC power output
YC6
1 MP MOT/A O 0/24 V DC
(pulse)
MP feed motor drive signal
Connected
to the MP
feed motor,
toner motor
and toner
container
detection
switch
2 24V O 24 V DC 24 V DC power output
3 MP MOT A O 0/24 V DC
(pulse)
MP feed motor drive signal
4 MP MOT B O 0/24 V DC
(pulse)
MP feed motor drive signal
5 24V O 24 V DC 24 V DC power output
6 MP MOT/B O 0/24 V DC
(pulse)
MP feed motor drive signal
7 TONER MOT/B O 0/24 V DC
(pulse)
Toner motor drive signal
8 TONER MOT/A O 0/24 V DC
(pulse)
Toner motor drive signal
9 TONER MOT B O 0/24 V DC
(pulse)
Toner motor drive signal
10 TONER MOT A O 0/24 V DC
(pulse)
Toner motor drive signal
11 SGND - - Signal ground
12 CONTENA SET I 0/5 V DC Toner container detection switch: On/off
13 N.C - - Not used
14 N.C - - Not used
YC7 A1 SGND - - Signal ground
Connected
to the deck
conveying
unit
A2 LCF SW B I 0/5 V DC Deck conveying switch 2: On/off
A3 5V O 5 V DC 5 V DC power output
A4 SGND - - Signal ground
A5 LCF SW A I 0/5 V DC Deck conveying switch 1: On/off
A6 5V O 5 V DC 5 V DC power output
A7 SGND - - Signal ground
A8 LCF SET I 0/5 V DC Deck conveying unit set signal
A9 SGND - - Signal ground
A10 N.C - - Not used
A11 5V O 5 V DC 5 V DC power output
A12 LCF SW A1 I 0/5 V DC Timing switch 1: On/off
B1 SGND - - Signal ground
B2 LIM SW1 I 0/5 V DC Lift limit switch 1: On/off
B3 5V O 5 V DC 5 V DC power output
B4 SGND - - Signal ground
B5 PE SW1 I 0/5 V DC Paper empty switch 1: On/off
Connector Pin No. Signal I/O Voltage Description
