2FB/2FC-3
1-4-10
U019
Displaying the ROM version
Description
Displays the part number for the ROM fitted to each PWB.
Purpose
To check the part number or to decide, based on the last digit of the number, if the newest version of ROM is
installed.
Method
1. Press the start key. The ROM version (the last 6 digits of the part number) is displayed.
2. Change the screen using the * or # keys.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
U020
Initializing all data
Description
Initializes the backup memory on the scanner PWB, DP main PWB and engine PWB in order to return to the
factory default settings.
Refer to *1 of the maintenance mode item list about the item initialized.
Purpose
To be executed as required.
Method
1. Press the start key. The screen for executing the maintenance item is displayed.
2. Press EXECUTE on the touch panel. It is displayed in reverse.
3. Press the start key. All data in the backup memory is initialized and the default setting for the inch spec-
ifications is registered. When initializing is complete, the machine automatically returns to the same sta-
tus as when the main power switch is turned on.
Completion
To exit this maintenance item without executing initialization, press the stop/clear key. The screen for selecting
a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
MAIN Main PWB ROM IC
ENGINE Engine PWB ROM IC
SCANNER Scanner PWB ROM IC
LANGUAGE (Stand.) Standard language ROM IC
LANGUAGE(Option) Optional language ROM IC
MAIN BOOT Main PWB booting
PRINTER Optional printer board booting
NETWORK SCANNER Optional network scanner ROM IC
DP DP ROM IC
FINISHER Optional document finisher main PWB ROM IC
ENGINE BOOT Engine PWB booting
FINISHER BOOT Optional document finisher main PWB booting
CASSETTE1 Deck PWB ROM IC
CASSETTE2 Cassette PWB ROM IC
DUPLEX Duplex PWB ROM IC
SIDE FEEDER Optional side feeder main PWB ROM IC
