2KN/2KP
2-3-31
YC9 1 5V O 5 V DC 5 V DC power output
Connected
to the origi-
nal size
detection
switch and
DP set
detection
switch
2 DPSW I 0/5 V DC DP set detection switch: On/off
3 GND - - Ground
4 5V O 5 V DC 5 V DC power output
5 ORGSW1 I 0/5 V DC Original size detection sensor: On/off
6 GND - - Ground
YC10 1 SMOT AN O 0/24 V DC (pulse) Scanner motor drive signal
Connected
to the scan-
ner motor
2 SMOT COM O 24 V DC 24 V DC power output
3 SMOT A O 0/24 V DC (pulse) Scanner motor drive signal
4 SMOT B O 0/24 V DC (pulse) Scanner motor drive signal
5 SMOT COM O 24 V DC 24 V DC power output
6 SMOT BN O 0/24 V DC (pulse) Scanner motor drive signal
Connector Pin No. Signal I/O Voltage Description
