Kyocera TASKalfa 620 - Parts Kits

2KN/2KP
2-4-10
Parts kits
Parts kit part name
Part No.
Altemative
Part No.
Fig.
No.
Ref.
No.
Name used in service manual Name
Parts kit A
Cleaning unit
Waste toner box
Image formation fan filter
Developing front fan filter 1
Cleaning unit protect cover
Fuser eject upper roller
Front cover filter 1
Front cover filter 2
Front cover filter 3
Developing front fan filter 2
Ozone filter 1
Ozone filter 2
Developing unit
Developing rear fan filter
Drum heater electrode
Separation pulley
DP original feed belt
DP forwarding pulley
DP separation roller
Cleaning felt
Forwarding pulley
Transfer roller
Press roller
Heat roller
Lower cleaning roller
Fuser joint gear
Heat roller separation claw
Heat roller gear
Main charger grid
Main charger cleaning pad
PTC cleaning pad
Transfer belt
Paper feed pulley
PM-660A/PM KIT
CLEANING ASS'Y
DISPOSAL TANK ASS'Y
FILTER MC FAN
FRONT FILTER DLP FAN
COVER CLN PROTECTION
UPPER ROLLER FUSER EJECT
FILTER FRONT COVER D
FILTER FRONT COVER E
FILTER FRONT COVER F
FRONT FILTER IMAGE FAN
OZONE FILTER B
OZONE FILTER C
DEVELOPING ASS'Y (SP)
REAR DLP FILTER B ASS'Y
PARTS,DRUM ELECTRODE ASS'Y
LOWER PULLEY FEED LCF
BELT PF
PULLEY LF
PULLEY SEPARATION
FELT,CLEANING
PULLEY LEADING FEED
ROLLER TRANSFER
ROLLER PRESSURE
ROLLER HEAT
LOWER ROLLER CLEANING
GEAR FUSER JOINT B
SEPARATOR FUSER ASSY
GEAR 50 HEAT ROLLER B
GRID ASS'Y
MC CLEANING PAD ASS'Y
PTC CLEANING PAD ASS'Y
PARTS TC BELT SP
PULLEY FEED LCF
1702KP0UN1 072KP0U1 44 -
Parts kit B
Cleaning felt
Forwarding pulley
Transfer roller
Press roller
Heat roller
Lower cleaning roller
Fuser joint gear
Heat roller separation claw
Heat roller gear
Main charger grid
Main charger cleaning pad
PTC cleaning pad
Transfer belt
Paper feed pulley
PM-660B/PM KIT
FELT,CLEANING
PULLEY LEADING FEED
ROLLER TRANSFER
ROLLER PRESSURE
ROLLER HEAT
LOWER ROLLER CLEANING
GEAR FUSER JOINT B
SEPARATOR FUSER ASSY
GEAR 50 HEAT ROLLER B
GRID ASS'Y
MC CLEANING PAD ASS'Y
PTC CLEANING PAD ASS'Y
PARTS TC BELT SP
PULLEY FEED LCF
1702KP0UN2 072FB0U2 44 -
