2KN/2KP
2-4-1
2-4 Appendixes
Maintenance parts list
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY FEED LCF 303KZ06270 3KZ06270 7
7
10
52
90
32
Forwarding pulley PULLEY LEADING FEED 2FB06040 - 7
7
10
47
85
27
Separation pulley LOWER PULLEY FEED LCF 303KZ06280 3KZ06280 7
10
41
36
MP paper feed pulley PULLEY FEED 2FB06060 - 9 40
MP forwarding pulley PULLEY LEADING FEED 2FB06040 - 9 36
MP separation pulley LOWER PULLEY FEED 2FB06080 - 9 22
Timing switch 1 SENSOR,CONVEYING 3H327410 - 7 92
Timing switch 2 SENSOR,CONVEYING 3H327410 - 7 69
Timing switch 3 SENSOR,CONVEYING 3H327410 - 10 38
Timing switch 4 SENSOR,CONVEYING 3H327410 - 10 38
Feed pulley UPPER ROLLER REGIST 302KP22010 2KP22010 13 46
Deck conveying roller LOWER ROLLER REGIST 2FB17030 - 13 15
Main charger unit PARTS,MC-650 302FB93031 2FB93031 17 A04
Main charger wire cleaning pad PARTS,MC CLEANING PAD ASS'Y SP 302FB94050 2FB94050 17 A06
Main charger wire WIRE,MAIN CHARGER 2A068240 - 17 23
Main charger grid PARTS,GRID ASS'Y SP 302FB94040 2FB94040 17 A05
Slit glass CONTACT GLASS,ADF 2BC12170 - 16 7
Contact glass CONTACT GLASS 35912010 - 16 6
Mirror 1 MIRROR A 2FB12140 - 15 35
Mirror 2 MIRROR B 2FB12180 - 15 30
Reflector REFLECTOR SCANNER 2FB12130 - 15 38
Exposure lamp LAMP SCANNER YG 302FB12440 2FB12440 15 40
Original size detection sensor SENSOR ORIGINAL 2C927090 - 15 58
Drum PARTS,DRUM ASS'Y 302FB93010 2FB93010 17 A02
Potential sensor SENSOR SURFACE POTENTIAL 302FB25090 2FB25090 32 9
Drum heater electrode PARTS,DRUM ELECTRODE ASS'Y 302FB93160 2FB93160 17 A01
Developing unit PARTS DV-660 302KP93140 2KP93140 18 A01
Transfer belt PARTS TC BELT SP 302FB93220 2FB93220 12 61
Transfer roller ROLLER TRANSFER 2FB16240 - 12 50
Idle belt roller IDLE BELT ROLLER 2FB16050 - 12 42
Transfer belt roller ROLLER BELT DRIVE 2FB16060 - 12 43
Transfer ground roller TC GROUND ROLLER 302FB16370 2FB16370 12 57
Transfer rear guide
PARTS,REAR TRANSFER GUIDE ASS'Y
302FB94170 2FB94170 12 A02
Transfer rear brush REAR BRUSH TRANSFER CLEANING 302FB16400 2FB16400 12 80
Cleaning unit PARTS CLEANING ASSY 302KP93160 2KP93160 19 A01
Cleaning lamp LAMP CLEANING 2FB27200 - 17 30
PTC unit PARTS,PTC ASS'Y 302FB93021 2FB93021 17 A03
PTC cleaning pad PARTS,PTC CLEANIG PAD ASS'Y SP 302FB94110 2FB94110 17 18
PTC wire TUNGSTEN WIRE(OX) SP (50M) 74669000 - 17 20
Lower cleaning roller LOWER ROLLER CLEANING 2FB20450 - 21 17
Press roller ROLLER PRESSURE 2FB20020 - 21 5
Press roller separation claw CLAW,PRESS ROLLER 36720493 - 21 70
Cleaning felt FELT CLEANING 302KP25170 2KP25170 21 59
Fuser thermistor THERMISTOR FUSER 302FB20200 2FB20200 21 35
