2KN/2KP
2-3-40
YC8 1 PF MOT1/A O 0/24 V DC (pulse) Paper feed motor 1 drive signal
Connected
to paper
feed motor 1
and 2
2 R24V O 24 V DC 24 V DC power output
3 PF MOT1 A O 0/24 V DC (pulse) Paper feed motor 1 drive signal
4 PF MOT1 B O 0/24 V DC (pulse) Paper feed motor 1 drive signal
5 R24V O 24 V DC 24 V DC power output
6 PF MOT1/B O 0/24 V DC (pulse) Paper feed motor 1 drive signal
7 PF MOT2 A O 0/24 V DC (pulse) Paper feed motor 2 drive signal
8 PF MOT2 B O 0/24 V DC (pulse) Paper feed motor 2 drive signal
9 PF MOT2/A O 0/24 V DC (pulse) Paper feed motor 2 drive signal
10 PF MOT2/B O 0/24 V DC (pulse) Paper feed motor 2 drive signal
YC10 1 SGND - - Signal ground
Connected
to cassette 2
level sensor
1/2/3, cas-
sette 2
detection
sensor and
lift motor 2
2 LCF2 SW1 I 0/5 V DC Cassette 2 level sensor 1: On/off
3 5V O 5 V DC 5 V DC power output
4 SGND - - Signal ground
5 LCF2 SW2 I 0/5 V DC Cassette 2 level sensor 2: On/off
6 5V O 5 V DC 5 V DC power output
7 SGND - - Signal ground
8 LCF2 SW3 I 0/5 V DC Cassette 2 level sensor 3: On/off
9 5V O 5 V DC 5 V DC power output
10 SGND - - Signal ground
11 LCF2 SW4 I 0/5 V DC Cassette 2 detection sensor: On/off
12 5V O 5 V DC 5 V DC power output
13
LIFT MOT2 L
O 0/24 V DC Lift motor 2: On/off
14
LIFT MOT2 H
O 0/24 V DC Lift motor 2: On/off
15 N.C - - Not used
YC11 1 MAIN MOT CLK O 0/5 V DC (pulse) Drive motor clock signal
Connected
to the drive
motor
2MAIN MOT
ALM
I 0/5 V DC Drive motor alarm signal
3MAIN MOT
REM
O 0/24 V DC Drive motor: On/off
4 5V O 5 V DC 5 V DC power output
5 SGND - - Signal ground
6 PGND - - Power ground
7 PGND - - Power ground
8 24V O 24 V DC 24 V DC power output
9 24V O 24 V DC 24 V DC power output
Connector Pin No. Signal I/O Voltage Description
