Kyocera TASKalfa 620 - Page 409

2KN/2KP
2-3-57
Connector Pin No. Signal I/O Voltage Description
YC1 1 24V I 24 V DC 24 V DC power input
Connected
to the scan-
ner PWB
2 24V I 24 V DC 24 V DC power input
3 24V I 24 V DC 24 V DC power input
4 A24V I 24 V DC 24 V DC power input
5 A24V I 24 V DC 24 V DC power input
6 PGND - - Power ground
7 PGND - - Power ground
8 PGND - - Power ground
9 5V I 5 V DC 5 V DC power input
10 5V I 5 V DC 5 V DC power input
11 SGND - - Signal ground
12 SGND - - Signal ground
13 AGND - - Analog ground
14 AGND - - Analog ground
15 SSCLK I 0/5 V DC (pulse) DP clock signal
16 SSDO O 0/5 V DC (pulse) DP serial communication signal
17 SSDI I 0/5 V DC (pulse) DP serial communication signal
18 SSEL I 0/5 V DC DP SEL signal
19 SRDY O 0/5 V DC DP ready signal
20 OVSYNC I 0/5 V DC OVSYNC signal
21 TMG2 O 0/5 V DC DP timing signal
22 FEED O 0/5 V DC DP FEED signal
YC2 1 RGDATA O 0/5 V DC CIS data signal
Connected
to the CIS
SHD PWB
2 RGCLK O 0/5 V DC (pulse) CIS clock signal
3 RGLD O 0/5 V DC CIS LD signal
4 RGRDWR O 0/5 V DC CIS RDWR signal
5 RGOUT O 0/5 V DC CIS OUT signal
6 AGND - - Analog ground
7 AGND - - Analog ground
8 A24V O 24 V DC 24 V DC power output
9 A24V O 24 V DC 24 V DC power output
10 SGND - - Signal ground
11 SGND - - Signal ground
12 5V O 5 V DC 5 V DC power output
13 5V O 5 V DC 5 V DC power output
14 WREST O 0/5 V DC CIS reset signal
15 PAGEST O 0/5 V DC PAGEST signal
16 PLLSEL0 O 0/5 V DC PLLSEL0 signal
17 PLLSEL1 O 0/5 V DC PLLSEL1 signal
18 WSCLK O 0/5 V DC (pulse) CIS clock signal
19 WSDO I 0/5 V DC (pulse) CIS serial communication signal
20 WSDI O 0/5 V DC (pulse) CIS serial communication signal
21 WSEL O 0/5 V DC CIS SEL signal
22 WRDY I 0/5 V DC CIS ready signal
